特点/用途
产品特点
恶劣环境下使用、数据传输稳定、导体及芯线均小绞距、抗疲劳，高耐磨绝缘、芯线退纽，减少应力、芯线不粘连，易脱皮
、高韧性，高弹性，耐磨护套、抗电磁干扰。
应用：这些电缆适用于人形机器人编码器设备上反复移动并保持高稳定的移动设备上。±270度扭转的机器人手臂或本体也适用，均需要层编织的保护以防止电磁干扰。
交货要求
交货要求： 按双方合同协议商定，允许不小于10米的短段交货。其数量应不超过交货总长度的10%。
技术参数
| 物料编码 | 规格mm2 | 外径mm | 铜重量kg/km | 电缆重量kg/km |
| RF465.0014.02 | 1X2X0.14 | 4.8 | 9.6 | 30.0 |
| RF465.0014.04 | 2X2X0.14 | 6.2 | 16.9 | 48.8 |
| RF465.0014.06 | 3X2X0.14 | 6.4 | 20.3 | 54.3 |
| RF465.0014.08 | 4X2X0.14 | 6.8 | 24.3 | 62.3 |
| RF465.0014.10 | 5X2X0.14 | 7.3 | 28.4 | 68.0 |
| RF465.0014.12 | 6X2X0.14 | 7.8 | 32.6 | 77.3 |
| RF465.0014.14 | 7X2X0.14 | 8.3 | 36.9 | 86.9 |
| RF465.0014.16 | 8X2X0.14 | 8.8 | 41.1 | 97.1 |
| RF465.0014.18 | 9X2X0.14 | 9.3 | 45.4 | 107.5 |
| RF465.0014.20 | 10X2X0.14 | 9.8 | 49.6 | 118.4 |
| RF465.0014.22 | 11X2X0.14 | 10.3 | 53.9 | 131.5 |
| RF465.0014.24 | 12X2X0.14 | 10.9 | 58.2 | 145.3 |
| RF465.0014.26 | 13X2X0.14 | 10.1 | 58.5 | 125.3 |
| RF465.0014.28 | 14X2X0.14 | 10.1 | 61.1 | 129.6 |
| RF465.0014.30 | 15X2X0.14 | 10.6 | 65.2 | 140.1 |
| RF465.0014.32 | 16X2X0.14 | 10.6 | 67.9 | 144.4 |
| RF465.0014.34 | 17X2X0.14 | 11.2 | 72.1 | 155.6 |
| RF465.0014.36 | 18X2X0.14 | 11.2 | 74.7 | 159.9 |
| RF465.0014.38 | 19X2X0.14 | 11.2 | 77.3 | 162.3 |
| RF465.0014.40 | 20X2X0.14 | 11.8 | 81.5 | 176.0 |
| RF465.0014.42 | 21X2X0.14 | 12.5 | 86.3 | 190.5 |
| RF465.0014.44 | 22X2X0.14 | 12.3 | 88.4 | 192.9 |
| RF465.0014.46 | 23X2X0.14 | 12.7 | 92.1 | 203.6 |
| RF465.0014.48 | 24X2X0.14 | 12.9 | 95.3 | 210.4 |
| RF465.0014.50 | 25X2X0.14 | 12.9 | 98.0 | 214.7 |
| RF465.0020.02 | 1X2X0.2 | 4.9 | 11.3 | 33.2 |
| RF465.0020.04 | 2X2X0.2 | 6.5 | 20.2 | 55.2 |
| RF465.0020.06 | 3X2X0.2 | 6.8 | 24.9 | 62.1 |
| RF465.0020.08 | 4X2X0.2 | 7.3 | 30.2 | 71.9 |
| RF465.0020.10 | 5X2X0.2 | 7.8 | 35.6 | 78.9 |
| 物料编码 | 规格mm2 | 外径mm | 铜重量kg/km | 电缆重量kg/km |
| RF465.0020.12 | 6X2X0.2 | 8.3 | 41.1 | 90.1 |
| RF465.0020.14 | 7X2X0.2 | 8.8 | 46.6 | 101.9 |
| RF465.0020.16 | 8X2X0.2 | 9.4 | 52.2 | 114.2 |
| RF465.0020.18 | 9X2X0.2 | 10.0 | 57.7 | 127.5 |
| RF465.0020.20 | 10X2X0.2 | 10.6 | 63.3 | 142.9 |
| RF465.0020.22 | 11X2X0.2 | 11.3 | 68.9 | 159.0 |
| RF465.0020.24 | 12X2X0.2 | 11.9 | 74.5 | 175.8 |
| RF465.0020.26 | 13X2X0.2 | 11.0 | 75.6 | 152.4 |
| RF465.0020.28 | 14X2X0.2 | 11.0 | 79.4 | 158.0 |
| RF465.0020.30 | 15X2X0.2 | 11.6 | 84.8 | 170.9 |
| RF465.0020.32 | 16X2X0.2 | 11.6 | 88.6 | 176.5 |
| RF465.0020.34 | 17X2X0.2 | 12.2 | 94.1 | 190.3 |
| RF465.0020.36 | 18X2X0.2 | 12.2 | 97.8 | 196.0 |
| RF465.0020.38 | 19X2X0.2 | 12.2 | 101.6 | 199.2 |
| RF465.0020.40 | 20X2X0.2 | 12.8 | 107.1 | 216.1 |
| RF465.0020.42 | 21X2X0.2 | 13.7 | 113.2 | 233.8 |
| RF465.0020.44 | 22X2X0.2 | 13.5 | 116.4 | 237.2 |
| RF465.0020.46 | 23X2X0.2 | 13.9 | 121.3 | 250.5 |
| RF465.0020.48 | 24X2X0.2 | 14.1 | 125.7 | 259.0 |
| RF465.0020.50 | 25X2X0.2 | 14.1 | 129.5 | 264.7 |
| RF465.0025.02 | 1X2X0.25 | 5.1 | 12.7 | 35.7 |
| RF465.0025.04 | 2X2X0.25 | 6.8 | 22.9 | 60.1 |
| RF465.0025.06 | 3X2X0.25 | 7.1 | 28.6 | 68.2 |
| RF465.0025.08 | 4X2X0.25 | 7.6 | 34.9 | 79.4 |
| RF465.0025.10 | 5X2X0.25 | 8.1 | 41.4 | 87.4 |
| RF465.0025.12 | 6X2X0.25 | 8.7 | 47.9 | 100.2 |
| RF465.0025.14 | 7X2X0.25 | 9.2 | 54.5 | 113.6 |
| RF465.0025.16 | 8X2X0.25 | 9.8 | 61.2 | 127.8 |
| RF465.0025.18 | 9X2X0.25 | 10.5 | 67.8 | 144.6 |
| RF465.0025.20 | 10X2X0.25 | 11.2 | 74.4 | 162.2 |
| 物料编码 | 规格mm2 | 外径mm | 铜重量kg/km | 电缆重量kg/km |
| RF465.0025.22 | 11X2X0.25 | 11.9 | 81.1 | 180.7 |
| RF465.0025.24 | 12X2X0.25 | 12.6 | 87.7 | 200.0 |
| RF465.0025.26 | 13X2X0.25 | 11.6 | 89.6 | 173.8 |
| RF465.0025.28 | 14X2X0.25 | 11.6 | 94.3 | 180.5 |
| RF465.0025.30 | 15X2X0.25 | 12.3 | 100.8 | 195.3 |
| RF465.0025.32 | 16X2X0.25 | 12.3 | 105.5 | 202.0 |
| RF465.0025.34 | 17X2X0.25 | 12.9 | 112.1 | 217.9 |
| RF465.0025.36 | 18X2X0.25 | 12.9 | 116.8 | 224.6 |
| RF465.0025.38 | 19X2X0.25 | 12.9 | 121.5 | 228.7 |
| RF465.0025.40 | 20X2X0.25 | 13.6 | 128.0 | 248.0 |
| RF465.0025.42 | 21X2X0.25 | 14.5 | 135.2 | 268.2 |
| RF465.0025.44 | 22X2X0.25 | 14.3 | 139.4 | 272.5 |
| RF465.0025.46 | 23X2X0.25 | 14.7 | 145.3 | 287.8 |
| RF465.0025.48 | 24X2X0.25 | 15.0 | 150.7 | 297.8 |
| RF465.0025.50 | 25X2X0.25 | 15.0 | 155.4 | 304.5 |
| RF465.0030.02 | 1X2X0.3 | 5.2 | 14.1 | 38.0 |
| RF465.0030.04 | 2X2X0.3 | 7.0 | 25.6 | 64.8 |
| RF465.0030.06 | 3X2X0.3 | 7.3 | 32.2 | 74.0 |
| RF465.0030.08 | 4X2X0.3 | 7.8 | 39.6 | 86.6 |
| RF465.0030.10 | 5X2X0.3 | 8.4 | 47.1 | 95.5 |
| RF465.0030.12 | 6X2X0.3 | 9.0 | 54.7 | 109.8 |
| RF465.0030.14 | 7X2X0.3 | 9.6 | 62.3 | 124.9 |
| RF465.0030.16 | 8X2X0.3 | 10.3 | 70.0 | 142.2 |
| RF465.0030.18 | 9X2X0.3 | 11.0 | 77.7 | 161.1 |
| RF465.0030.20 | 10X2X0.3 | 11.8 | 85.4 | 180.9 |
| RF465.0030.22 | 11X2X0.3 | 12.5 | 93.1 | 201.6 |
| RF465.0030.24 | 12X2X0.3 | 13.3 | 100.8 | 223.3 |
| RF465.0030.26 | 13X2X0.3 | 12.2 | 103.5 | 194.6 |
| RF465.0030.28 | 14X2X0.3 | 12.2 | 109.1 | 202.4 |
| RF465.0030.30 | 15X2X0.3 | 12.9 | 116.6 | 219.0 |
| RF465.0030.32 | 16X2X0.3 | 12.9 | 122.3 | 226.8 |
| RF465.0030.34 | 17X2X0.3 | 13.6 | 129.9 | 244.6 |
| RF465.0030.36 | 18X2X0.3 | 13.6 | 135.5 | 252.5 |
| RF465.0030.38 | 19X2X0.3 | 13.6 | 141.2 | 257.3 |
| RF465.0030.40 | 20X2X0.3 | 14.3 | 148.8 | 279.0 |
| RF465.0030.42 | 21X2X0.3 | 15.2 | 157.0 | 301.7 |
| RF465.0030.44 | 22X2X0.3 | 15.0 | 162.1 | 306.8 |
| RF465.0030.46 | 23X2X0.3 | 15.5 | 169.1 | 324.0 |
| RF465.0030.48 | 24X2X0.3 | 15.8 | 175.4 | 335.4 |
| RF465.0030.50 | 25X2X0.3 | 15.8 | 181.1 | 343.3 |
| RF465.0034.02 | 1X2X0.34 | 5.3 | 15.1 | 39.8 |
| RF465.0034.04 | 2X2X0.34 | 7.2 | 27.6 | 68.5 |
| RF465.0034.06 | 3X2X0.34 | 7.5 | 35.0 | 78.5 |
| RF465.0034.08 | 4X2X0.34 | 8.0 | 43.2 | 92.1 |
| RF465.0034.10 | 5X2X0.34 | 8.6 | 51.6 | 101.8 |
| RF465.0034.12 | 6X2X0.34 | 9.3 | 60.0 | 117.3 |
| RF465.0034.14 | 7X2X0.34 | 9.9 | 68.5 | 134.0 |
| RF465.0034.16 | 8X2X0.34 | 10.7 | 77.0 | 153.5 |
| RF465.0034.18 | 9X2X0.34 | 11.4 | 85.5 | 173.9 |
| RF465.0034.20 | 10X2X0.34 | 12.2 | 94.1 | 195.4 |
| RF465.0034.22 | 11X2X0.34 | 13.0 | 102.6 | 217.9 |
| RF465.0034.24 | 12X2X0.34 | 13.7 | 111.1 | 241.5 |
| RF465.0034.26 | 13X2X0.34 | 12.6 | 114.4 | 210.8 |
| RF465.0034.28 | 14X2X0.34 | 12.6 | 120.8 | 219.5 |
| RF465.0034.30 | 15X2X0.34 | 13.3 | 129.2 | 237.5 |
| RF465.0034.32 | 16X2X0.34 | 13.3 | 135.6 | 246.2 |
| RF465.0034.34 | 17X2X0.34 | 14.1 | 144.0 | 265.6 |
| RF465.0034.36 | 18X2X0.34 | 14.1 | 150.4 | 274.3 |
| RF465.0034.38 | 19X2X0.34 | 14.1 | 156.8 | 279.7 |
| RF465.0034.40 | 20X2X0.34 | 14.8 | 165.3 | 303.3 |
| RF465.0050.02 | 1X2X0.5 | 6.0 | 20.9 | 52.3 |
| RF465.0050.04 | 2X2X0.5 | 8.4 | 38.7 | 94.1 |
| RF465.0050.06 | 3X2X0.5 | 8.8 | 50.1 | 109.6 |
| RF465.0050.08 | 4X2X0.5 | 9.5 | 62.3 | 130.4 |
| RF465.0050.10 | 5X2X0.5 | 10.4 | 74.8 | 146.2 |
| RF465.0050.12 | 6X2X0.5 | 11.3 | 87.4 | 173.3 |
| RF465.0050.14 | 7X2X0.5 | 12.3 | 100.1 | 202.1 |
| RF465.0050.16 | 8X2X0.5 | 13.3 | 112.8 | 232.8 |
| RF465.0050.18 | 9X2X0.5 | 14.2 | 125.5 | 265.1 |
| RF465.0050.20 | 10X2X0.5 | 15.2 | 138.2 | 299.1 |
| 物料编码 | 规格mm2 | 外径mm | 铜重量kg/km | 电缆重量kg/km |
| RF465.0050.22 | 11X2X0.5 | 16.2 | 151.0 | 334.8 |
| RF465.0050.24 | 12X2X0.5 | 17.2 | 163.7 | 372.2 |
| RF465.0050.26 | 13X2X0.5 | 15.8 | 169.7 | 323.1 |
| RF465.0050.28 | 14X2X0.5 | 15.8 | 179.7 | 337.3 |
| RF465.0050.30 | 15X2X0.5 | 16.7 | 192.2 | 365.7 |
| RF465.0050.32 | 16X2X0.5 | 16.7 | 202.1 | 380.0 |
| RF465.0050.34 | 17X2X0.5 | 17.8 | 226.3 | 423.7 |
| RF465.0050.36 | 18X2X0.5 | 17.8 | 236.3 | 438.0 |
| RF465.0050.38 | 19X2X0.5 | 17.8 | 246.3 | 446.8 |
| RF465.0050.40 | 20X2X0.5 | 18.8 | 259.5 | 485.0 |
| RF465.0075.02 | 1X2X0.75 | 5.8 | 26.2 | 54.1 |
| RF465.0075.04 | 2X2X0.75 | 9.1 | 49.1 | 112.8 |
| RF465.0075.06 | 3X2X0.75 | 9.6 | 64.6 | 132.9 |
| RF465.0075.08 | 4X2X0.75 | 10.5 | 81.1 | 161.7 |
| RF465.0075.10 | 5X2X0.75 | 11.5 | 98.0 | 183.3 |
| RF465.0075.12 | 6X2X0.75 | 12.6 | 114.9 | 218.0 |
| RF465.0075.14 | 7X2X0.75 | 13.7 | 131.9 | 255.0 |
| RF465.0075.16 | 8X2X0.75 | 14.8 | 149.0 | 294.4 |
| RF465.0075.18 | 9X2X0.75 | 15.9 | 166.0 | 335.8 |
| RF465.0075.20 | 10X2X0.75 | 17.0 | 183.1 | 379.4 |
| RF465.0075.22 | 11X2X0.75 | 18.3 | 212.1 | 438.8 |
| RF465.0075.24 | 12X2X0.75 | 19.4 | 230.0 | 487.7 |
| RF465.0075.26 | 13X2X0.75 | 17.8 | 238.3 | 425.3 |
| RF465.0075.28 | 14X2X0.75 | 17.8 | 252.3 | 444.4 |
| RF465.0075.30 | 15X2X0.75 | 18.8 | 269.8 | 481.6 |
| RF465.0075.32 | 16X2X0.75 | 18.8 | 283.8 | 500.7 |
| RF465.0075.34 | 17X2X0.75 | 19.9 | 301.5 | 540.8 |
| RF465.0075.36 | 18X2X0.75 | 19.9 | 315.4 | 559.8 |
| RF465.0075.38 | 19X2X0.75 | 19.9 | 329.4 | 571.9 |
| RF465.0075.40 | 20X2X0.75 | 21.0 | 347.1 | 620.9 |
| RF465.0100.02 | 1X2X1.0 | 6.8 | 32.2 | 71.4 |
| RF465.0100.04 | 2X2X1.0 | 9.8 | 60.7 | 133.5 |
| RF465.0100.06 | 3X2X1.0 | 10.4 | 81.1 | 160.8 |
| RF465.0100.08 | 4X2X1.0 | 11.5 | 102.6 | 197.8 |
| RF465.0100.10 | 5X2X1.0 | 12.6 | 124.4 | 224.7 |
| RF465.0100.12 | 6X2X1.0 | 13.8 | 146.3 | 268.2 |
| RF465.0100.14 | 7X2X1.0 | 15.1 | 168.3 | 314.3 |
| RF465.0100.16 | 8X2X1.0 | 16.3 | 190.4 | 363.5 |
| RF465.0100.18 | 9X2X1.0 | 17.7 | 224.0 | 428.3 |
| RF465.0100.20 | 10X2X1.0 | 19.0 | 247.0 | 483.7 |
| RF465.0100.22 | 11X2X1.0 | 20.2 | 270.0 | 541.8 |
| RF465.0100.24 | 12X2X1.0 | 22.0 | 340.8 | 657.1 |
| RF465.0100.26 | 13X2X1.0 | 19.7 | 305.3 | 526.9 |
| RF465.0100.28 | 14X2X1.0 | 19.7 | 323.9 | 551.5 |
| RF465.0100.30 | 15X2X1.0 | 20.8 | 346.5 | 598.0 |
| RF465.0100.32 | 16X2X1.0 | 20.8 | 365.1 | 622.6 |
| RF465.0100.34 | 17X2X1.0 | 22.5 | 437.0 | 728.3 |
| RF465.0100.36 | 18X2X1.0 | 22.5 | 455.6 | 752.9 |
| RF465.0100.38 | 19X2X1.0 | 22.5 | 474.2 | 768.8 |
| RF465.0100.40 | 20X2X1.0 | 23.7 | 499.8 | 833.0 |
| RF465.0150.02 | 1X2X1.5 | 7.4 | 93.8 | 89.0 |
| RF465.0150.04 | 2X2X1.5 | 11.1 | 182.4 | 174.2 |
| RF465.0150.06 | 3X2X1.5 | 11.8 | 221.8 | 212.6 |
| RF465.0150.08 | 4X2X1.5 | 13.0 | 274.3 | 263.5 |
| RF465.0150.10 | 5X2X1.5 | 14.4 | 313.6 | 300.8 |
| RF465.0150.12 | 6X2X1.5 | 15.9 | 387.2 | 371.9 |
| RF465.0150.14 | 7X2X1.5 | 17.3 | 453.9 | 436.1 |
| RF465.0150.16 | 8X2X1.5 | 18.8 | 524.7 | 504.2 |
| RF465.0150.18 | 9X2X1.5 | 20.1 | 583.8 | 560.7 |
| RF465.0150.20 | 10X2X1.5 | 21.5 | 660.9 | 634.8 |
| RF465.0150.22 | 11X2X1.5 | 23.6 | 819.2 | 788.4 |
| RF465.0150.24 | 12X2X1.5 | 25.0 | 909.2 | 874.8 |
| RF465.0150.26 | 13X2X1.5 | 22.9 | 801.5 | 772.2 |
| RF465.0150.28 | 14X2X1.5 | 22.9 | 836.9 | 807.6 |
| RF465.0150.30 | 15X2X1.5 | 24.3 | 906.9 | 874.4 |
| RF465.0150.32 | 16X2X1.5 | 24.3 | 942.3 | 909.7 |
| RF465.0150.34 | 17X2X1.5 | 25.7 | 1017.2 | 981.2 |
| RF465.0150.36 | 18X2X1.5 | 25.7 | 1052.6 | 1016.6 |
| RF465.0150.38 | 19X2X1.5 | 25.7 | 1076.3 | 1040.3 |
| RF465.0150.40 | 20X2X1.5 | 27.1 | 1166.4 | 1126.8 |
